FRP Truck body , fiberglass sandwich truck body , Dry cargo truck body , dry box truck body
This 10 - 25 m3 FRP / fiberglass sandwich truck body could be used for Transporting Dry cargo, fresh vegertable, milk, icecream, frozen fish, meat, and so on. The volume could be as your request, but the width not over 2300mm, the height not over 2570mm. Notice the 20ft and 40ft container inner size please, we need ship it by container.
FUNCTIONS
| TRUCK | Truck body panels |
| CKD truck body panels | Cargo box |
| truck cargo body | Dry cargo body |
| Insulated cargo body | Dry truck body |
| Insulated truck body | FRP truck body |
| FRP cargo box | Refrigerated truck body |
| meat transport truck body | Freezer truck body |
| cargo van body | truck van body |
| cargo van box | van truck body |
| van box | Isolated truck body |
| Material |
| Surface | Fibreglass reinforced plastic |
| Intermediate layer | PP honeycomb composited, |
| Edge Protector | Aluminium alloy,aluminium,stainless steel |
| Door seal | EPDM rubber |
| Door frame & Locks | 304 stainless steel |
Specifications:
| Term | Refrigerated truck body |
| Standard thickness | Front/rear/side panel: 83mm roof/floor panel: 103mm The thickness can be changed according to customer’s requirements. |
| Refrigerator brand | Thermo king, origin USA Carrier, origin USA Kaixue, origin China etc. |
| Temperature | -18 Celsius -20 Celsius -22 Celsius -24 Celsius |
| Dimension of panel | Length 0-15000mm Width 0-3100mm Height 0-3100mm Thickness 33, 43, 63, 83, 103mm |
| Main characters insulated body | 1. Light in weight: 40% lighter than metal body. 2. Better insulation: K value less than 0.3w/m2k.. 3. High in strength and long life: 5 times longer than metal body. 4. Non-corrosion, non-pollution, anti-brine, acid and soda-resisting. 5. Easy to be assembled and repaired at site |
| Packing | In CBU (completely built up) and CKD (completely knock down) type |
Our Product Advantages
(1) Competitive Factory Price and Excellent Quality
(2) More than 40 years' experience as a manufacturer, more than 12 years exporting experience.Export to more than 30 countries and regions.
(3) Perfect after-sale service.One year quality guarantee or within 100000km, which comes first.The overseas engineers are always ready to deal with unexpected needs.
(4) Products Quality Certification SGS CCC ISO.Customized products available with us
